Rockfort Fosgate Power 33 cm (13”) T2 Single 2-Ohm Subwoofer T2S2-13
1.599,00 €
Technical Specifications:
Speaker Connector | 8 AWG slot loaded |
Power Handling (Watts RMS) | 2000 Watts RMS 4000 Watts Max |
Nominal Impedance | 2-Ohm |
Size | 33 cm (13”) |
Vas (Liters) | 68.7 |
Xmax (mm) | 34 |
Qms | 3.01 |
Cutout Diameter | 12.28 in. (312 mm) |
Fs (Hz) | 25.5 |
Mounting Depth | 9.70 in. (246 mm) |
Voice Coil Diameter | 3.96″ (100 mm) |
Woofer Displacement | 0.250 cu. ft. (7.08 Liters) |
Sd (cm2) | 707 |
Qts | 0.35 |
Qes | 0.40 |
Le (mH) | 0.91 |
SPL (dB @ 1w/1m) | 87 |
Magnet Weight (oz) | 528 oz. (14.97 Kg) |
SPL (dB @ 2.8v/1m) | 90 |
Re (Ohms) | 1.6 |
Subwoofer Type | Standard |
Voice Coil Type | Single Voice Coil |
Sealed Box Volume (Vb) | 1.85 cu. ft. (52.3 Liters) |
Vented Box Volume (Vb) | 4.0 cu. ft. (113 Liters) |
Shipping Weight | 93.70 Lbs. (42.5 Kg.) |
- Description
- Reviews (0)
- PDF MANUAL
Description
The Power T2S2-13 subwoofer features 13-inches of effective radiating cone area and a single 1-ohm voice coil for ease of wiring.
This subwoofer is not just another made with off-the-shelf parts, we wanted something better, and we knew our fanatics demand this as well. Since the original Power T2 subwoofer was designed by one of the leading loudspeaker engineers in the world, there were some lofty goals that had to be reached. Work was done from the ground-up to out-perform it’s previous family members, while incorporating valuable feedback from our great network of Rockford Fosgate dealers. They wanted it bigger and badder with dual everything, and we feel that goal was crushed.
Why 13-inches? Well, this is a combination of the cone and surround assembly described as the “total effective radiating area”. Since this model is so massive, we incorporated dual spiders for exceptional travel of the cone assembly. The motor structure operates very linear for exceptional sonic quality and the IDHS heat-sink gives the subwoofer impressive power handling capacity. Top it off with proprietary input terminals for large gauge cables to efficiently deliver the needed voltage, and this subwoofer is ready to drop the doom!
