P2D2-10 Rockfort Fosgate Punch 25 cm (10″) P2 2-Ohm DVC Subwoofer
179,00 €
| Power Handling (Watts RMS) | 300 Watts RMS 600 Watts Max |
| Vas (Liters) | 35.4 |
| Qms | 7.00 |
| Qes | 0.54 |
| Size | 25 cm (10”) |
| Nominal Impedance | Dual 2-Ohm |
| Mounting Depth | 5.92 in. (150.4 mm) |
| Voice Coil Diameter | 2.25″ (57.15 mm) |
| SPL (dB @ 1w/1m) | 84 |
| Woofer Displacement | 0.060 cu. ft. (1.7 Liters) |
| Le (mH) | 3.32 |
| Xmax (mm) | 11 |
| Magnet Weight (oz) | 66.4 oz. (1.88 kg.) |
| Fs (Hz) | 29 |
| Shipping Weight | 13.6 Lbs. (6.16 kg) |
| Speaker Connector | Dual 10 AWG compression |
| Qts | 0.50 |
| Re (Ohms) | 3.20 |
| Cutout Diameter | 9.13 in. (232 mm) |
| Sd (cm2) | 360 |
| Subwoofer Type | Standard |
| Voice Coil Type | Dual Voice Coil |
| Sealed Box Volume (Vb) | 0.59 cu. ft. (16.7 Liters) |
| Vented Box Volume (Vb) | 1.4 cu. ft. (39.6 Liters) |
- Description
- Reviews (0)
- PDF MANUAL
Description
The Rockford Fosgate P2 10 inch subwoofer for cars and trucks continues “The PUNCH” tradition. The P2D2-10 sub features a Dual 2-Ohm voice coil (DVC), 300 Watts RMS power handling, and can accommodate a grille insert using the included cast aluminum trim ring.
Rockford Fosgate has always been known as “The PUNCH” and the P2 10″ Punch car subwoofer certainly continues with the tradition. Kevlar fiber reinforced paper cones deliver bass impact you can feel along with VAST technology to increase surface cone area up to 25%. The P2 10 inch subwoofers perform best in standard sealed and vented enclosures. Includes diamond cut cast aluminum trim ring. Optional grille insert available.
FEATURES AT A GLANCE
- High-temp voice coil with spun-laced Nomex® re-inforcement collar
- Dual linear spider with embedded 16 AWG tinsel leads
- Protective PVC textured magnet cover
- Extended pole piece and bumped vented backplate
- StampCast basket with integrated spider venting
- Custom 10-AWG nickel plated push terminals
- Diamond cut cast aluminum trim ring with optional grille
- Kevlar fiber reinforced paper cone
